FEATURES
PARAMETERS
SPECIFICATION
ADVANTAGES
APPLICATION
FEATURES
- ABS plastic moulding
- Apertures accepting a wide range of bus bar
- CTs are ultrasonically welded and unbreakable
PARAMETERS
| Ordering code | Ratio | Class | Burden (VA) | ….. |
| VIPS 401-150/5-3-2.5 | 150/5 | 3 | 2.5 | ….. |
| VIPS 401-200/5-1-2.5 | 200/5 | 1 | 2.5 | ….. |
| VIPS 401-250/5-1-2.5 | 250/5 | 1 | 2.5 | ….. |
| VIPS 401-300/5-1-2.5 | 300/5 | 1 | 2.5 | ….. |
| VIPS 401-400/5-1-5 | 400/5 | 1 | 5 | ….. |
| VIPS 401-500/5-0.5-5 | 500/5 | 0.5 | 5 | ….. |
| VIPS 401-600/5-0.5-5 | 600/5 | 0.5 | 5 | ….. |
| VIPS 401-750/5-0.5-5 | 750/5 | 0.5 | 5 | ….. |
| VIPS 401-800/5-0.5-5 | 800/5 | 0.5 | 5 | ….. |
SPECIFICATION
| Rated Primary current | : | 150 A to 800 A | ….. |
| Rated Secondary output | : | 5 A | ….. |
| Rated Burden | : | 2.5 VA , 5 VA and 7.5 VA | ….. |
| Thermal nominal continuous | : | 1.2 times rated current continuously | ….. |
| Rated Current | : | 2.55x Ith | ….. |
ADVANTAGES
- Easy bus bar mounting
- Highly cost effective
- Compact in size
APPLICATION
| » Switchgear | » Distribution System | ….. |
| » Generator sets | » Control panels | ….. |
| » Control Devices | » Overload Protection | ….. |
