FEATURES
SPECIFICATION
ADVANTAGES
APPLICATION
FEATURES
- ABS plastic moulding
- Apertures accepting a wide range of bus bar
- CTs are ultrasonically welded and unbreakable
SPECIFICATION
| Rated Primary current | : | 200 A to 1600 A | ….. |
| Rated Secondary output | : | 5 A | ….. |
| Rated Burden | : | 1 VA and 0.5 VA | ….. |
| Thermal nominal continuous | : | 1.2 times rated current continuously | ….. |
| Rated Current | : | 2.55x Ith |
ADVANTAGES
- Easy bus bar mounting
- Highly cost effective
- Compact in size
APPLICATION
| » Switchgear | » Distribution System | ….. |
| » Generator sets | » Control panels | ….. |
| » Control Devices | » Overload Protection | ….. |
